Operation
Left joystick
137 / 476
6.5 Left joystick
As soon as the left joystick console is folded up, the machine drive and the drive train
stop automatically.
ADVICE
All functions can only be executed with the joystick if the seat console is swung down
all the way and the machine is operated in operating mode Turtle I or Turtle II. Or if
the machine is operated in operating mode Rabbit I or Rabbit II and the main steering
switch is unlocked.
Joystick movements
FORWARD Lower pile pickup
BACKWARD Raise pile pickup
RIGHT Swivel pile pickup (completely) to the right
LEFT Swivel pile pickup (completely) to the left
