Operating Components
Driver's cabin cylinder support
61 / 476
5.2 Driver's cabin cylinder support
The driver's cabin must not be raised or lowered unless both pickup side sections are
folded out and if the driver is sure that there is no obstacle within a height of 5.3 m
above the driver's cabin.
1
Cylinder support engaged
1
Cylinder support in parking position
DANGER
Risk of fatal injuries
The driver's cabin may lower without warning.
– The cylinder support (1) must be engaged before working under the driver's cabin.
– Return the cylinder support to parking position before lowering the driver's cabin.
