Operating Components
Air conditioning
89 / 476
5.9 Air conditioning
1
1
1
3
4
2
5
5
5
5
6
(1) Air vents in the roof console (view from below)
(2) Circulating air grate in the rear wall
(3) Rotary open/closed switch circulating air grate
(4) Temperature sensor for the air conditioning system
(5) As example: air vents in the right A column of the driver’s cabin
(6) Air vents in the footwell
