Maintenance and Service
Mechanical drive for steering axles
339 / 476
7.4 Mechanical drive for steering axles
7.4.1 Cardan shafts from gearbox to the steering axles
All cardan shafts at the machine must be lubricated every 200 operating hours.
DANGER
Hazard to life due to rotating machine parts!
When the engine is running, body parts or pieces of clothing may be caught by rotat-
ing drive shafts and pulled into the machine.
– Stop the machine and shut down diesel engine.
– The machine must be secured against inadvertent starting of the engine.
Illustration shows a grease nipple
