Malfunction and Remedies
Electrics
395 / 476
8.2.4 List of self-resetting electronic fuses with LED
No. Function Pos. in the machine
B26 PS traction drive forward
F70r
B61 PS brake-pressure service brake
B20 PS pick up roller
F71r
B21 PS 4-fold pinch rollers
B22 PS cleaning
F72r
B27 PS additional axles
B68 PS relief pickup, right
F73r
B69 PS relief pickup, left
B377 PS fuel pressure
F74r
B60 PS air chamber reservoir pressure
B84 PS traction drive backward
F75r
B85 PS clutch PDG
B80 PS emergency steering pump
F76r
B94 telescopic pile pickup sensor
B46 volume fuel tank
F77r
B67 PS relief pick up middle
B638 Mercedes fine filter fuel pressure
F78r
B83 PS pickup conveyor rollers
B01 front axle wheel angle sensor
F79r
B02 rear axle wheel angle sensor
in central electrics box
24V
