Operating Components
Operating console R-Concept
81 / 476
5.7.5 Keypad II
355541
7
5
3
1
8
6
4
2
(1) STOP diesel engine:
Key to stop the engine.
(2) START diesel engine:
Key to start the engine.
(3) Air conditioning system ON/OFF/de-icing: see page 283.
(4) Light - working lights: see page 128.
(5) Raise/lower additional axles: see page 164.
The additional axles are lowered when the LED lights.
(6) Window wipers (all except for the front windscreen): see page 113
(7) Service key:
E.g. required for activating of automatic folding.
(8) Water spray system (option) see page 245
