Malfunction and Remedies
Electrics
390 / 476
8.2 Electrics
8.2.1 Fuses
The fuses for the electric system are located in the seat console and in the box for the
central electric system on the outside outside on the cabin platform. For the machine,
mainly commercially available, flat plug-in fuses (melting fuses) are used.
Labels on the inside of the metal cover identify the fuses. There are also three elec-
tronic automatic cut-outs in the slots of the reserve fuse holder in the central electrical
system.
The electronic automatic cut-outs are not integrated into the electric circuits and may
therefore be used by you in searching for faults. For this purpose, plug in a suitable
electronic automatic cut-out in the socket for the blown fuse. In case of overload (for
instance short circuit), the automatic cut-out will be triggered. The electronic automatic
cut-out can be reactivated by pressing on the reset button.
Fuses in the central electrics
