Maintenance and Service
Truck conveyor
370 / 476
7.12.2 Rotary drives for swivel arm and truck conveyor
The swivel arm and truck conveyor are driven hydraulically by two chain drives. The
chains are automatically tensioned by hydraulic cylinders.
DANGER
Hazard of extremely severe injuries by chain drives!
– Stop the machine and shut down diesel engine.
– The machine must be secured against inadvertent starting of the engine.
Falling hazard!
– Always use approved and safe ladders and climbing aids or an approved work plat-
form for all work on the drives for the swivel arm and truck conveyor.
– Never climb on the machine.
Rotating truck conveyor chain drive
If necessary, adjust the grease brushes (1) and make sure that the contact areas of
the chain links on the sprocket are always coated with grease.
1
