Maintenance and Service
Air conditioning and ventilation system
376 / 476
7.14.2 Recirculating filter
The recirculating filter (1) is located in the cabin floor behind the driver‘s seat, under a
covering hood.
1
2
This filter must be cleaned in case of
need. For this purpose:
– Remove the cover. For this purpose
turn the locks by 90° counterclockwise
and pull out.
– Pull out the recirculating filter (1)
upward by the flap (2).
– Blow out recirculating filter using com-
pressed air.
– Reinsert the cleaned recirculating fil-
ter. Pay attention to the flow direction.
The printed arrow (3) on the filter must
point in the direction of windscreen.
– Reinstall cover hood.
This filter element (ROPA
item no. 352422) should be renewed
once a year in any case.
3
7.14.3 Fresh air intake filter
The fresh air intake filter (1) for the driver's cabin is located right, outside on the rear
cabin wall.
