Malfunction and Remedies
Color codes for electric wiring
399 / 476
8.4 Color codes for electric wiring
Color codes for electric wiring
brown Ground
red Pin 30 (continuous current)
pink Pin 15 (ignition current)
yellow 8.5 Volt
violet 12 Volt
blue Digital signal lines (ON/OFF)
green Analogue signal lines (changing sensor values)
grey All lamps “E” light bulbs and “H” warning devices (buzzer)
white Electrical motors and internal wiring, miscellaneous
orange Control lines for all valves and solenoids (all „Y“)
Feature: twisted cables
white (twisted) = CAN-high
brown (twisted) = CAN-low
twisted together = CAN-BUS data line
