8.3 Relays list
No. Designation Position in
the machine
Comments Item No.
K03 Relay direction indicator Roof console Flasher unit 320871
K01 Relay main load pin 15 Load relay pin 15, 70 A 320099
K04 Relay fan module/park heating 320154
K06 Relay window wiper switches the front wiper motor 320573
K07 Relay central lubrication switches the central lubricating
pump
320154
K08 Relay side window wiper left switches left side window wiper 320154
K09 Relay side window wiper right switches right side window wiper 320154
K10 Relay rear window wiper switches rear window wiper 320154
K11 Relay door window wiper switches door window wiper 320154
K12 Roof headlights switches 4 units WL roof front 320154
K13 Headlights cleaning/truck
conv.
switches WL cleaning/truck conv. 320154
K15 Back run buzzer relay for back run buzzer + video
switchover
320154
K17 Relay air conditioning control
device/park heating
to switch from air conditioning con-
trol device pin 15 into pin 30
320154
K19 Relay rotating beacons
in central
electrics box
switches all rotating beacons 320154
K43 Battery relay in battery case electrically operated battery main
switch
320762
