8.5 Searching for malfunctions using R-Touch
Value too low
B10 pickup depth
Some malfunctions are indicated on the R-Touch by warning icons. In case of elec-
trical or electronic problems, the components concerned are displayed including the
designation of the component.
Example:
= Communications problem with control device A03 = com-
puter ESR E (refer to the table below).
= Analogue signal out of range.
= Line break or short circuit found.
= Internal memory fault EEPROM.
