Operation
Water spray system (option)
254 / 476
6.14.2.5 Duo water spray system (option)
With the optional Duo water spray system one additional water valve is installed in
each side pickup section and in the recleaner. This water valve switches additional
spray nozzles. These water valves are switched on and off individually with the "+"
switch panel (21) (22) (26). The timer control and pressure control also actuate the
additional water valves.
21 22
26
6.14.2.6 Configuring water spray programs
Water spray programs 1-3 can be individually assigned as desired. To do this switch
on the spray nozzles you want to save to a program. Press and hold one of the pro-
gram keys (13-15) to save the currently active nozzles to a program.
Main menu
13 14 15
Water spray system
