Operation
Folding the machine out/in
179 / 476
WARNUNG
Hazard of extremely severe injuries.
– Make sure, that nobody stands in the hazard zones when the machine is started.
The following processes are executed automatically. During these processes,
several movements are performed simultaneously:
1 The speed of the diesel engine increases.
2 The counterweight is raised up to the end-stop.
3 The lock of the counterweight arm opens up to the end-stop.
4 The counterweight arm swivels a little to the left thereby enabling complete opening
of the lock.
5 The truck conveyor is raised only slightly above the lateral transport support.
6 The truck conveyor turns to the right and out of the machine perimeter.
7 The recleaner swivels into working position.
8 The swivel arm is unlocked.
9 The truck conveyor is raised, simultaneously the truck conveyor articulation is
swung up.
10 If "Loading direction left" was preselected, then at the rear of the machine the com-
pletely lowered truck conveyor crosses over with the counterweight (lift up to the
end-stop).
11 As soon as these processes are completed, the diesel engine switches to idling
speed.
If automatic folding is not entirely completed, you can intervene at any time and
manually perform completion of the folding procedure (see page 188)
ATTENTION
Always pay attention that there is sufficient free space behind the machine allowing
implementation of this movements. In addition, there must be sufficient ground clear-
ance.
6.12.3 Folding in machine automatically rear
– Remove large accumulations of soiling and deposits of earth. Pay particular atten-
tion that the area around the lower pivot point of the roller recleaner is free of earth
deposits.
– If at all possible, use automatic fold-in (saves time).
– Check whether the folding/swiveling area of the truck conveyor and counterweight
arm are free of obstacles, transport vehicles or people.
– Turn the rotatable seat forward to the right or left until it almost reaches the end-
stop and until the rotatable seat status display on the R-Touch becomes green (dis-
play between 80 and 100%).
