Operation
Diesel engine
144 / 476
6.6.2 Shut down diesel engine
Let the engine run for a short time idling before shutting it down. If the engine is shut
down at high speed, then the turbo charger runs on after the oil pressure has already
fallen.
This leads to lack of lubricant and therefore to unnecessary wear on bearings of the
turbo charger running at high speed.
– Put ignition lock in the position 0
or
– press STOP key
6.6.3 Engine speed adjustment
Operating mode "Rabbit"
By sliding the X-Y key (16) to the right/left on the left joystick, it is possible to switch
between driving with manual engine speed control (to the left) and automotive dri-
ving (to the right). To switch, the X-Y key (16) must be slid into the respective direc-
tion and shortly held in this position.
15
17
16
Automatic engine speed adjustment (automotive driving)
During automotive driving adjustment of the engine speed is exclusively performed
using the driving pedal.
14
Manual adjustment of the engine speed
Manual engine speed adjustment in the operating mode "Rabbit" can only be per-
formed using the manual potentiometer (14). The highest engine speed is at about
1500 rpm. This variant is the most suitable for driving on uneven terrain.
