Operation
Pump distributor gears
268 / 476
6.16 Pump distributor gears
6
The pump distributor gears is directly flanged to the diesel engine and transfers engine
power to the individual hydraulic pumps. The hydraulic pumps required for loading are
connected by a multiple disc clutch. Briefly press the yellow key (6) on the right joystick
to switch this clutch and thus the machine drive on and off.
The pump distributor gears are fitted with pressure circulation lubrication. If lubrication
is not sufficient, then a warning signal sounds.
The R-Touch shows the warning icon .
ATTENTION
Hazard of severe damage to the machine.
– Immediately switch off the engine if the warning signal sounds with the engine run-
ning.
ADVICE
The highest allowed diesel engine rotating speed for the hydraulic pumps drive may
not be exceeded, not even for a short time.
Maximum speed:
machine drive switched off (with constant throttle brake): 2700 min
-1
machine drive switched on: 1975 min
-1
