ROPA Maus 5 - Adjusting Counterweight Arm Lock Stop Screws

Maintenance and Service
Truck conveyor
373 / 476
7.12.2.2 Adjusting counterweight arm lock stop screws
As soon as the clamp is no longer rigid, the stop screws (1) must be adjusted. This
requires loosening the lock nuts (2) on the stop screws and adjusting the screws until
there is no more play.
1
1
2
Counterweight arm lock
1
1
2
