Operation
Loading operation
221 / 476
1
6
5
4
3
2
The greater your experience with the
machine, the better your precision at esti-
mating the optimum speeds.
(1) Rpm pickup rollers
(2) Rpm conveyor rollers
(3) Rpm 4 pinch rollers
(4) Rpm infeed conveyor
(5) Rpm recleaning
(6) Rpm truck conveyor
6.13.7 Truck conveyor (drive A)
The truck conveyor moves the beets from the recleaner to the transport vehicle. The
beets should be treated as gently as possible during this process.
6
This drive is switched on or off jointly with the machine drive using the yellow button
(6) on the right joystick.
Rpm truck conveyor
Choose this function with R-Select.
+ key = truck conveyor faster
- key = truck conveyor slower
If this drive is stopped, all forward drives will also stop. This drive can not be reversed.
If this drive is overloaded, then the following icon is displayed on the R-Touch.
If the truck conveyor is blocked, then the following icon is displayed on the R-
Touch.
