Operation
Scales (option)
259 / 476
6.15.2.2 Commissioning after delivery of machine
The scales must always be calibrated before using for the first time. The calibration is
performed in two stages, which must be performed in the sequence described every
time. (see page 264)
ADVICE
If a component of the scales (except for the speed sensor, in some cases also the
inclination sensor) is replaced, it must be recommissioned. This process can only be
performed by service technicians and is not described in this manual.
6.15.2.3 Start/end weighing
5
Weighing started: scales icon green
background
5
Weighing finished or interrupted: scales
icon black background
To start weighing touch the switch panel
(5).
To end or stop weighing also touch the
switch panel (5).
