7.1.6 SCR exhaust after-treatment with AdBlue
®
The machine is equipped with an SCR exhaust after-treatment system. In any case,
comply with the notes on handling AdBlue
®
(see page 459).
2
1
(1) AdBlue® filler neck
(2) AdBlue® tank
3
4
(3) AdBlue® pump module
(4) Filter housing AdBlue® pump module
ATTENTION
Danger of machine damage!
Even filling in small amounts of other liquids leads to great damage to the SCR
exhaust after-treatment system. No accommodation will be granted for such damage.
– Utmost cleanliness must be ensured when filling up AdBlue®.
– The AdBlue® tank may be filled with AdBlue® only, do not fill in water or other
liquids. A sensor in AdBlue® tank permanently measures the quality (urea con-
centration). If the quality is not sufficient, the diesel engine reduces its output, the
machine is no longer ready for operation.
