Operation
Loading operation
216 / 476
6.13.4.3 Relieving the pickup central section
The relief pressure of the central part is set using the mini joystick (1) so that the front
axle is loaded. This improves traction of the front tires and the drive train is more
evenly loaded.
9
7
(7) Relief pressure mid
(9) Pickup height in %
There is no guideline value for the relief pressure of the central section. The only deci-
sive criterion is how it appears on the video display You should see here that all beets
are picked up and that no beet losses occur.
Display on the central mark camera showing how optimal adjustment looks. No beet
fragments, bearing assembly of the pickup roller visible over the ground.
