Operation
Scales (option)
258 / 476
6.15.2.1 Operation of scales
Scales
Amount day
Amount season
Zeroing
Calibration
Amount limit scales
Menu Scales
Amount day (see page 267)
Amount season (see page 267)
Zeroing (see page 261)
Calibration (see page 264)
Amount limit scales (see page 260)
Display field Scales
9
5
6
7
8
10
11
to:
Summe Tag:
12
(5) Start/end of weighing process
(6) Reset current weighed amount
(7) Current weighed amount
(8) Amount day (counter is not automatically set to 0)
(9) Display of loading angle (inclination of truck conveyor articulation)
(10) Amount limit scales
(11) Weighing display active (green)
(12) Status indicator bar showing load of weighing cells
