ROPA Maus 5 - 4-Set Pinch Rollers in the Pickup (Drive D)

Operation
Loading operation
230 / 476
6.13.10 4-set pinch rollers in the pickup (drive D)
The 4-set pinch rollers in the pickup move the beets to the center of the pickup onto
the infeed conveyor. They only move in the feed direction when the machine drive is
switched on and the infeed conveyor is running.
These pinch rollers may also be reversed when the infeed conveyor stops.
8
To switch on the 4-set pinch rollers, briefly press
the key (8) once on the right joystick.
If this key is briefly pressed again, the 4-set pinch
rollers stop.
If this key is pressed and held pressed, then
the rotating direction of the 4-set pinch rollers is
reversed.
Rpm 4 pinch rollers
The rotary speed of the 4-set pinch rollers can be
adjusted in ten steps. Choose this function with R-Select.
+ key = increase rotational speed (more aggressive
cleaning and transport)
- key = reduce speed (gentler cleaning and transport)
To treat the beets as carefully as possible, the speed of 4 pinch rollers should not be
selected higher than necessary.
If the key + is released after the stage 10 is reached and then pressed for at least
three seconds, the "Max" stage is reached. The highest hydraulic drive speed
is achieved in the "Max" stage. The stage "MAX" should only be used in case of
extremely sticky soil. In this stage, the rotational speed of the 4 pinch roller is only
dependent on the rotational speed of the diesel engine.
