Operation
Loading operation
232 / 476
Rpm conveyor rollers
Choose this function with R-Select.
+ key = increase speed (rollers rotate faster)
- key = decrease speed (rollers rotate slower)
To treat the beets as carefully as possible, the speed of the conveyor rollers should
not be selected higher than necessary.
At faster conveyor roller speeds, many beets are transported to the extreme outside
edge. Thus, the cleaning path is extended. This is recommended if the beets are
highly soiled.
The speed of the eccentric drive of the central mark is synchronous to the speed of
the conveyor rollers (due to series connection of the hydraulic motors).
If the warning limit of the conveyor rollers is exceeded, the following warning icon is
displayed on the R-Touch.
If the conveyor rollers are blocked, then the following warning icon is displayed on
the R-Touch.
If the conveyor rollers are blocked, the pickup roller drive is shut off.
6.13.12 Pickup rollers (drive F)
