Lubricating plans
456 / 476
9.8 Lubricating plans
9.8.1 Central lubrication circle 1 pickup
75
75 Conveyor roller 3
105
105
Pinch roller 4
25
105*
25*
105*
105
105 Cleaning roller coupling hook
Pickup roller coupling hook
Pinch roller 3
Conveyor roller 2
Conveyor roller 1
Pinch roller 2
Pickup roller gearing
Pickup roller
Pinch roller 1
Cleaning roller
75
75 Conveyor roller 1
105
105
Pinch roller 2
105
105 Pickup roller gearing
Pickup roller
Pinch roller 1
Cleaning roller
Conveyor roller 3
Pinch roller 4
Cleaning roller coupling hook
Pickup roller coupling hook
Pinch roller 3
Conveyor roller 2
75
105
25 Eccentric bearing
Drive central mark bearing
Ball head
Universal joint yoke
Pivot front
45
45
75
Raise pickup cylinder
105
105 GE bearing flaps left rear
GE bearing flaps left front
Fold tie rod cylinder left
Lift pickup pivot right
Raise pickup cylinder
GE bearing flaps right rear
GE bearing flaps right front
Fold tie rod cylinder right
Lift pickup pivot right
Sub-distributor pickup frame
To main distributor circuit 2
Return line
ROPA item no.: 360163
Sub-distributor central mark
ROPA item no.: 360157
Sub-distributor pickup right
ROPA item no.: 360159
Sub-distributor pickup left
ROPA item no.: 360158
Main distributor circuit 1
ROPA item no.: 360156
Chassis
