Malfunction and Remedies
Electrics
397 / 476
No. Function Pos. in the machine
Sensors operating with 8.5V, feeding from A01
B74 rpm conveyor rollers right
F91r
B75 rpm conveyor rollers left
B76 fold pickup right
F92r
B77 fold pickup left
B72 rpm infeed conveyor
F93r
B08 pile pickup side sensor
B70 pile pickup height sensor
F94r
B71 rpm truck conveyor
B88 locking counterweight arm
F95r
B89 rotate recleaner rear
B180 height of bar truck loader transport support
F96r
B79 sensor rotary seat
B95 residual beet pickup sensor Rotate
F97r
B96 water tank level sensor
in central electrics box
8.5V
