Malfunction and Remedies
Electrics
396 / 476
No. Function Pos. in the machine
Sensors operating with 8.5V, feeding from A02
--- B40 temperature hydraulic fluid
directly from A02/23, via
R09
B86 sensor counterweight arm r/l
F80r
---
B47 driving speed (2 drive engine model)
F81r
---
B73 Cab height
F82r
B87 counterweight up/down sensor
B32 drive pedal sensor (safety)
F83r
---
B34 truck conv. height sensor
F84r
B35 truck conv. articulation sensor
B51 Sensor PDG greasing
F85r
B47 driving speed (1 drive engine model)
in central electrics box
8.5V
No. Function Pos. in the machine
Sensors operating with 8.5V, feeding from A03
B62 rpm pick up rollers right
F86r
---
B63 rpm pickup rollers left
F87r
---
B64 rpm 4 pinch rollers right
F88r
B10 pickup depth sensor
B65 rpm 4 pinch rollers left
F89r
B66 rpm recleaning
B09 driving pedal sensor (work)
F90r
---
in central electrics box
8.5V
