Maintenance and Service
Truck conveyor
371 / 476
Check the chain wear one a year as described below and replace the chain immedi-
ately it reaches the wear limit (305 mm).
max. 305 mm
DANGER
Hazard of fatal injuries by uncontrolled rotary movements of swivel arm and
truck conveyor if the chain jumps off the sprocket.
– Stop the machine immediately and have the machine checked by a mechanic.
Swivel arm chain drive
