Operation
Operating modes "Turtle" and "Rabbit"
154 / 476
Switch on differential lock of rear axle:
It is not possible to lock the rear axle alone. The lock of the rear axle can only acti-
vated if the differential lock of the front axle has been switched on. If, on the other
hand, the differential lock for the front axle is switched off, then automatically the differ-
ential lock for the rear axle is switched off as well.
– To switch on the differential lock completely release the gas pedal and stop the
vehicle.
– Press the key (4) on the keypad I.
– The icon appears on the R-Touch if the engagement position of the axle is not
achieved. The LED flashes.
– The icon appears on the R-Touch if the differential lock is engaged. The LED is
lit.
ADVICE
The rear axle is only able to perform limited steering tasks with the differential lock
engaged. If larger steering movements of the rear axle are required, then first switch
off the differential lock of the rear axle.
Front axle differential lock not released
Rear axle differential lock not released
Switch off differential lock:
– You can switch both differential locks with the key (3) on the keypad I. The LED
does not light.
– You can switch the differential lock of the rear axle with the key (4) on the keypad I
The LED does not light.
– If one of the following icons appears on the R-Touch after switching off the differ-
ential lock: - then an axle is locked and therefore the differential lock is not
completely released yet. This lock may be released by deliberately steering this
axle back and forth.
The differential lock will be switched automatically off with switching to the operating
mode "Rabbit II".
