Operation
Folding the machine out/in
199 / 476
– Turn swivel arm into transport position. When the swivel arm reaches the transport
position, a value of 0 (±20) is displayed on the R-Touch in the display field "Swivel
arm position" (7). The activated swivel arm lock automatically latches in position
and is displayed like this (8).
5
Swivel arm locked
7
8
