Maintenance and Service
Diesel engine
305 / 476
– This pipe is not commercially available, but may be self-made without any problem.
It should be long enough to reach the bottom of the cartridge.
– Set the pressure reducer to max. 5 bar and blow out the filter cartridge so long
using dry compressed air, until no dust emission occurs anymore. During blowing
out, constantly move the compressed air gun up and down and constantly rotate
the filter.
max. 5 bar
max. 72 psi
ADVICE
The tip of the pipe should not come into contact with the filter paper! Before refitting
the cleaned main element must be carefully examined for damage to the paper belows
and seals.
