Maintenance and Service
Axles
346 / 476
Proceed as follows for changing the oil:
– Change the oil only with gears warm after operation.
– Park the machine on level ground.
– Put an oil-resistant collecting vessel of sufficient size underneath.
– Unscrew the oil drain bolt of the differential gear. It is located at the bottom, at the
lowest part of the axle body.
– Open the oil level control screw and wait until the oil has drained completely.
– Reinsert the oil drain screw.
– Fill in oil through the oil filling opening for so long until the oil level reaches the
lower edge of the oil filling opening.
– Screw the oil level control screw in again.
Prescribed oil variants: Gear oil
API GL5, SAE 90
Filling volume: approx. 22 litres Front axle
approx. 20 litres Rear axle
