Maintenance and Service
Recleaning
367 / 476
The 8.set pinch roller cleaner is driven by a hydraulic motor.
The oil level of the gearbox must be checked once a week. The oil level is checked at
the inspection glass. If the oil level is above the middle of the glass, it is not necessary
to add oil.
The first oil change is due after 50 operating hours, then the oil must be changed once
a year.
3
2
1
(1) Oil filling screw
(2) Inspection glass
(3) Oil drain screw
Proceed as follows for changing the oil:
– Change the oil only with gears warm after operation.
– Put an oil-resistant collecting vessel of sufficient size underneath.
– Turn off the closing cap of the oil drain screw.
– Open the oil level filling screw and wait until the oil has drained completely.
– Reinsert the oil drain screw.
– Add oil into the oil filling opening until the oil level is in the upper section of the
inspection glass.
– Screw on the oil filler cap.
Prescribed oil variants: Gear oil
API GL5, SAE 90
Filling volume: approx. 6.0 litres
