ROPA Maus 5 - Page 392

Malfunction and Remedies
Electrics
392 / 476
No. Ampere Function
F03 10
Battery main switch, ladder lighting, park heating
timer
Pin 30
F04 15 Pin 30 A403 CPC4 Mercedes
F05 15 Pin 30 A02 computer ESR B
F06 15 Pin 30 A02 computer ESR B
F07 15 Pin 30 A03 computer ESR C
F08 15 Pin 30 A03 computer ESR C
F09 40 Pin 30 A435 MCM Mercedes
F10 15 Pin 30 A22 I/O module II
F11 15 Pin 30 A23 I/O module III
F12 15 Pin 30 A24 I/O module I
F13 15
24 V outlet rear
Inside light central electrics
F14 15 Heater fan with park heating operation
F15 15 Pin 30 park heating
F16 3
Air conditioning control unit with park heating
operation
F17 15 Pin 30 A21 I/O module I
F18 15 Pin 30 A01 computer ESR A
F19 15 Pin 30 A01 computer ESR A
F20 40 Pin 30 A95 ACM Mercedes
F21 15 Pin 30 A34 I/O module V
Pin
30
from X1
F22 15 Outlet 24V engine bracket
F23 10 Hazard warning system
F24 15 Rotating beacons
F25 15 K12 roof headlights
F26 15 K13 headlights cleaning/truck conv.
F27 10 Current transformer
Pin
30
from X2
F28 7.5 Parking light right front, left rear
F29 7.5 Parking light left front, right rear, switch lighting.
from light
F30 15 Pin 30 roof console
F31 10 Window wiper rear
F32 10 Window wiper door
Pin
30
from X2
