ROPA Maus 5 - Page 45

General View and Specifications
General view
45 / 476
47
48
49
50
51
52
53
54
55
4645
59
45
58
57
56
(45) Fold plates
(46) Clearing shield
(47) Pinch roller 4
(48) Pinch roller 3
(49) Pinch roller 2
(50) Pinch roller 1
(51) Conveyor roller 3
(52) Conveyor roller 2
(53) Conveyor roller 1
(54) Cleaning roller
(55) Pickup roller
(56) Pickup rollers
(57) Conveyor rollers
(58) 4 pinch rollers
(59) Frost breakers
60
(60) Central mark
