Section 08 ENGINE MANAGEMENT (4-TEC)
Subsection 03 (DIAGNOSTIC PROCEDURES)
RESPONSIBLE MODULE
FAULT
CODE
INFORMATION
CENTER
MPEM ECM
BEEPER
CODE
WARNING
LIGHT
MESSAGE
DISPLAYED
(info ctr)
FAULT
DETECTED
WHILE ENGINE
NOT RUNNING
FAULT
DETECTED
WHILE ENGINE
RUNNING
LIMP
HOME
MODE
NORMAL
OPERATION
RESUME
WHEN...
P0563 — —
Battery voltage
too high
15 Flash N/A N Y N
Fault is
recovered
Possible cause:
Battery failure, rectifier failure or battery terminal connection.
Service action:
Check for regulator-rectifier failure.
P0600 — —
CAN
communication
problem detected
by EMS
15 Flash N/A Y Y N
Fault is
recovered
Possible cause:
Damaged circuit wires, damaged connector, damaged ECM output pins.
Diagnostic connector cap not connected.
Service action:
Check system circuits 1-16 & 1-17, 1-10 & 1-11, 2-10 & 2-11.
Connect diagnostic connector cap.
P0600 — —
CAN
communication
problem MPEM
message missing
15 Flash N/A Y Y N
Fault is
recovered
Possible cause:
Damaged circuit wires, damaged connector or damaged ECM output pins.
Service action:
Check system circuits 2-10 & 2-11.
P0601 — —
TPS learns
unlikely or
checksum fault
15 Flash
CHK
ENG
— — — —
Possible cause:
ECM not coded, damaged ECM or TPS not initialized.
Service action:
Check cable adjustment.
Check idle stop for wear.
Check throttle angle at idle.
Reset closed TPS.
P0601 — —
Module call
monitoring
15 Flash
CHK
ENG
— — — —
Possible cause:
Damaged ECM.
Service action:
Key on and off.
Reset closed TPS.
Check battery voltage.
Replace TPS.
456 smr2004-Complete Line Up
