Section 09 COOLING SYSTEM

Subsection 01 (CIRCUIT, COMPONENTS AND CARE)

CIRCUIT, COMPONENTS AND CARE

717 Engines

F17E0ES

Loctite

567

Loctite

567

Bleed

hose

Water

injection

hose

Tuned pipe

water

inlet hose

Loctite

567

Engine

drain hose

Engine water

supply hose

Engine

water

return

hose

1.2 Nm

(11 lbfin)

Pump support

Loctite

567

smr2004-Complete Line Up 467
