Section 06 ENGINE MANAGEMENT (RFI)
Subsection 03 (COMPONENT INSPECTION )
RFI SENSORS RESISTANCE VALUES
COMPONENT
TERMINAL
NUMBER
WIRE COLOR
RESISTANCE
VALUE
VOLTS
1and2 PU/BL and BK/BL 2.4 k - 8.2 k ohms
5 Vdc between
PU/BL and BK/BL
Air pressure sensor
9and2 WH/BL and BK/BL 3.4 k - 8.2 k ohms
3and4 PU/BW and BK/BW 1.6 k - 2.4 k ohms
Throttle position
sensor
4 and 11 BK/BW and WH/BW 710 - 1380 ohms
5 Vdc between
PU/BW and BK/BW
Water temperature
sensor
5 and 12 BK/OR and TA/OR 2280 - 2736 ohms N.A.
Air temperature
sensor
6 and 13
BK/WH and WH/GY
2280 - 2736 ohms N.A.
Crankshaft position
sensor
7 and 14
GY/YL and GY/RE
774 - 946 ohms N.A.
Rave solenoid 16 and 23
PU/GY and BK/GY
30 ohms N.A.
Injector
no. 1
18 and 20 BL/PU and BL/BK 2.3 - 2.5 ohms
Injector
no. 2
19 and 21
GR/PU and BK/GR
2.3 - 2.5 ohms
6Vdcattheplug
connector
N.A.: Not Applicable
smr2004-Complete Line Up 317
