SeaDoo GTI - Magneto System

Section 04 ENGINE (2-STROKE)
Subsection 03 (MAGNETO SYSTEM)
MAGNETO SYSTEM
717 Engines
24
Loctite
243
5
5 Nm
(44 lbfin)
9 Nm
(80 lbfin)
16
Loctite
243
4
6
7
Loctite
243
6 Nm
(53 lbfin)
23
6 Nm
(53 lbfin)
22
Loctite 243
3
6 Nm
(53 lbfin)
15
Loctite
243
14
13
150 Nm
(110 lbfft)
Loctite
648
25
1
12
11
10 Nm (89 lbfin)
Anti-seize
lubricant
10 Nm
(89 lbfin)
11
Anti-seize
lubricant
10 Nm
(89 lbfin)
11
2.6 Nm
(23 lbfin)
2
F02D12S
