Section 06 ENGINE MANAGEMENT (RFI)
Subsection 02 (DIAGNOSTIC PROCEDURES )
FAULT CODE TABLES
ECU Faults
FAULT CODE
FAULT DETECTION
MPEM programmer B.U.D.S.
TYPE OF FAULT
No fault detected FF FF 88 N.A.
• No defect
FF FF 00 P0604
• Internal defect
Electronic Control Unit
Internal memory
FF FF 1B P0605
• Not plausible = EEPROM defect
Electronic Control Unit
EEPROM
FF FE 2B P1600
• EEPROM not programmed
FF FD 10 P1601
• Data in EEPROM out of range
(1 of 3 bytes)
EEPROM Data Setting
FF FD 25 P1602
• Data in EEPROM out of range
(all 3 bytes different)
Input Signal Faults
FAULT CODE
FAULT DETECTION
MPEM programmer B.U.D.S.
TYPE OF FAULT
02 14 07 P0562
• Voltage from the battery too low
Supply voltage to ECU
02 14 06 P0563
• Voltage from the battery too high
02 0A 1D P0117
• Sensor circuit shorted to ground
02 0A 1E P0118
• Signal interruption or short circuit to battery
Engine Water
Temperature Sensor
(WTS)
02 0A 1B P0116
• Non plausible signal
02 06 1F P0122
• Sensor circuit shorted to ground
Throttle Position Sensor
(TPS)
02 06 1C
P0123
• Sensor circuit shorted to battery
Crankshaft Position
Sensor (CPS)
02 1F 06
02 1F 23
P0219
• Signal exceeding RPM limits
02 01 03 P0335
• No signal detected (fault code active when
engine is not running and ignition is on)
Crankshaft Position
Sensor (CPS)
02 01 1B P0336
• Synchronization error
(sensor/toothed wheel)
02 0F 1D P0112
• Sensor circuit shorted to ground
Air Intake Temperature
Sensor (ATS)
02 0F 1E P0113
• Signal interruption or short circuit to battery
02 10 1D P0107
• Sensor circuit shorted to ground
Air Pressure Sensor
(APS)
02 10 1E P0108
• Signal interruption or short circuit to battery
