Section 12 ELECTRICAL SYSTEM

Subsection 03 (STARTING SYSTEM)

STARTING SYSTEM

717 Engines

F00H1PS

Loctite 243

Loctite

271

Ground

cable

22 Nm

(16 lbfft)

Loctite

243

22 Nm

(16 lbfft)

22 Nm

(16 lbfft)

5 Nm

(44 lbfin)

Dielectric

grease

smr2004-Complete Line Up 575
