Section10FUELSYSTEM
Subsection 02 (AIR INTAKE (2-STROKE))
ASSEMBLY
Assembly is essentially the reverse of removal
procedures. However pay particular attention to
the following.
CAUTION: Do not modify air intake system,
otherwise calibration will be affected.
Flame Arrester Base
On 717 engines, apply Loctite 518 on mating sur-
faces of flame arrester base no. 9.
Apply Loctite 243 (blue) on screws no. 10 and
torque to 10 N•m(89lbf•in).
Flame Arrester
Inspect condition of flame arrester no. 6. Replace
or clean as necessary.
WARNING
Do not operate watercraft without flame ar-
rester.
Gasket
Inspect condition of gasket no. 2. Makesureto
properly install gasket.
514 smr2004-Complete Line Up
