Section 05 ENGINE (4-TEC)

Subsection 06 (LUBRICATION SYSTEM)

LUBRICATION SYSTEM

R1503motr368S

4-TEC

Supercharged

only

Loctite 243

10 Nm

(89 lbfin)

Loctite 243

10 Nm

(89 lbfin)

24 Nm

(18 lbfft)

Loctite

5910

Loctite 243

10 Nm

(89 lbfin)

Oil

3 Nm

(27 lbfin)

Left handed

threads

Loctite 243

10 Nm

(89 lbfin)

Loctite 243

12 Nm

(106 lbfin)

Oil

Multi-purpose

grease

Loctite 243

10 Nm

(89 lbfin)

Oil

smr2004-Complete Line Up 235

www.SeaDooManuals.net
