Section 05 ENGINE (4-TEC)

Subsection 05 (PTO HOUSING/MAGNETO)

Only use supercharger spray nozzle installer to

push in the nozzle no. 23. Use retaining screw

hole to ensure the exact position.

R1503motr265A

1. Spray nozzle installer

2. Screw hole for positioning
