Section 01 SERVICE TOOLS AND PRODUCTS

Subsection 01 (MANDATORY SERVICE TOOLS )

STEERING SYSTEM

O.P.A.S. cylinder nut wrench

(P/N 529 035 840)

APPLICATION

Models equipped with the

O.P.A.S. system.
