Section 08 ENGINE MANAGEMENT (4-TEC)
Subsection 03 (DIAGNOSTIC PROCEDURES)
RESPONSIBLE MODULE
FAULT
CODE
INFORMATION
CENTER
MPEM ECM
BEEPER
CODE
WARNING
LIGHT
MESSAGE
DISPLAYED
(info ctr)
FAULT
DETECTED
WHILE ENGINE
NOT RUNNING
FAULT
DETECTED
WHILE ENGINE
RUNNING
LIMP
HOME
MODE
NORMAL
OPERATION
RESUME
WHEN...
P1502 — —
TOPS functional
problem
5 Flash
CHK
ENG
Y N/A 5000
Engine is
stopped
Possible cause:
Boat or sensor upside down, damaged circuit wires, damaged connector or damaged ECM output pins.
Service action:
Check for circuit continuity between pins 2-2 and B-9.
P1509 —
Lake temperature
sensor circuit out
of range
— 15 Off SENSOR Y Y N N/A
Possible cause:
Damaged sensor, damaged circuit wires, damaged connector or damaged MPEM output pins.
Service action:
Check for 6528.3 to 25403.3 ohms between system circuits 2-13 and 2-4.
P1510 —
Lake temperature
sensor circuit
low voltage
— 15 Flash SENSOR Y Y N N/A
Possible cause:
Damaged sensor, damaged circuit wires, damaged connector or damaged MPEM output pins.
Service action:
Check for no continuity between system circuit 2-13 and battery ground.
Connect or disable lake water temperature sensor in setting page.
P1511 —
Lake temperature
sensor circuit
high voltage
— 15 Off SENSOR Y Y N N/A
Possible cause:
Damaged sensor, damaged circuit wires, damaged connector or damaged MPEM output pins.
Service action:
Check for 6528.3 to 25403.3 ohms between system circuits 2-13 and 2-4.
Connect or disable lake water temperature sensor in setting page.
P1513
Exterior
temperature
sensor circuit
low voltage
— — 15 Off SENSOR Y Y N N/A
Possible cause:
Damaged sensor, damaged circuit wires, damaged connector or damaged MPEM output pins.
Service action:
Check for 200 to 24000 ohms between pins 1 and 9 of the instrument cluster harness connector.
Connect or disable exterior air temperature sensor in setting page.
P1514
Exterior
temperature
sensor circuit
high voltage
— — 15 Off SENSOR Y Y N N/A
Possible cause:
Damaged sensor, damaged circuit wires, damaged connector or damaged MPEM output pins.
Service action:
Check for 200 to 24000 ohms between pins 1 and 9 of the instrument cluster harness connector.
Connect or disable exterior air temperature sensor in setting page.
460 smr2004-Complete Line Up
