Section17TECHNICALDATA
Subsection 04 (RXP 4-TEC MODELS)
ELECTRICAL RXP 4-TEC
TOPS
10 A
Battery fuse 30 A
Cylinder 1, ignition coil and injection 10 A
Cylinder 2, ignition coil and injection 10 A
Cylinder 3, ignition coil and injection
10 A
Electric bilge pump (optional) 3A
Starting system, electric fuel pump
10 A
EMS, start/stop circuit 5A
Main 30 A
MPEM Not applicable
Charging system
30 A
Information center 1A
Fuse
VTS 7.5 A
ADDITIONAL INFORMATION:
FUEL SYSTEM RXP 4-TEC
Fuel injection type
Rotax EMS (engine management system) Multipoint
Fuel Injection. Single throttle body (52 mm (2.05 in))
Fuel pressure
56 PSI - 60 PSI
Idle speed (in water/out of water) 1800 ± 50 RPM
Throttle Position Sensor (TPS)
1.6 k -2.4k
Crankshaft Position Sensor (CPS) 190 - 290
Camshaft Position Sensor (CAPS) 12 volts
Camshaft Position Sensor (CAPS)
1.2 k
Manifold Air Temperature Sensor (MATS)
2.28 k -2.74k
Coolant Temperature Sensor (CTS)
2.28 k -2.74k
Exhaust Gas Temperature Sensor (EGT) 2.28 k -2.74k
Manifold Air Pressure Sensor (MAPS)
6040 (terminals 2-1)
5554
(terminals 3-2)
5822
(terminals 3-1)
Knock Sensor (KS)
5M
Oil Pressure Switch (OPS) 0 , if oil pressure is greater than 26 - 32 PSI
Oil Separator Pressure Switch (OSPS) 0 , if blow-by pressure is less than 6 PSI
TOPS valve
1.27 -2.47
Fuel injector 11.4 - 12.6
INSIDE NORTH AMERICA
Recommended
Premium
unleaded gasoline with 91 octane
(Ron + Mon)/2 specification for optimum performance
Minimum
Regular
unleaded gasoline with
87 octane (Ron + Mon)/2 specification
OUTSIDE NORTH AMERICA
Recommended
Premium
unleaded gasoline with 95 octane RON
specification for optimum performance
Type
Minimum
Regular
unleaded gasoline with 91 octane
RON specification
Fuel
Minimum oc
tane no.
See above
ADDITIONAL INFORMATION:
