DMG 3200/3100/3000 ā User Manual
Page 113 (306)
The following information is displayed:
Stream ID
The SimulCrypt Stream ID used towards the CA system. Its value is also set to
the SimulCrypt EcmId.
Name
For reference in the GUI only
ECM
Generator
Links the ECM to the predefined ECMG
SCG ID
CW selection; all ECMs with the same SCG id will share the same CW.
AC Type
Access Criteria type ā refers to the data type used over the SimulCrypt protocol
when the access criteria are transferred. Available types are: UTF16, INT32, or
HEX.
Access
Criteria
Specified in decimal or HEX (use 0x prefix)
Private Data
Private descriptor data added to the ca_descriptor in the PMT; enter in HEX
using the 0x prefix.
PID
Preferred ECM PID value transmitted at the output module; the maximum value
is 8191.
State
OPEN or CLOSE
CP Number
This is a reference number for both CAS and scrambler. It represents the
number of exchanges between the ECMG and the scrambler; the value is
either Automatic or configurable.
If multiple ECMG connections have been defined, the same SCG ID may be used for two
ECMs as long as they are connected to different ECMGs.
At this point, the ECM stream is defined and the CA system as well as the SCS
module can begin to exchange CW and ECMs. However, the ECM is still not
associated to any output. Refer to the Output Configuration chapter for details on
how to associate ECMs to outputs.
To change an, ECM configuration click on the existing ECM entry and enter the new
configuration.
