DMG 3200/3100/3000 ā User Manual
Page 148 (306)
Configuration of the output streams and ports are similar to that of the standard IP output and
these details are shown in 8.4.1.
7.4.2.1 Unique Configuration on two ports
IP settings can be configured different on the two IP ports in cloned output mode. Parameters
that are able to be changed, can be selected and the new value entered. By default, the
properties of port A are used.
Figure 7.35 āUnique configuration on two output ports
7.4.2.2 Exclusive Output Port Mode
While in Cloned IP output mode, it is possible to enable Exclusive Output in which the following
rules are followed:
Link on both ports
(Default)
Port A is active
Port B is inactive (ie no output bitrate)
Link on B port only
(link down on A
port)
Port A is inactive (link down)
Port B is active
Link on A port only
(link down on B
port)
Same effect as default
When the module is in exclusive output mode only one port is outputting transport streams at
once. If link is down on one port, the other port will take over.
