DMG 3200/3100/3000 – User Manual
Page 231 (306)
• None: No audio will be associated with profile.
• Audio 1: Audio 1 transcoded by this block (A/B/C/D) will be
associated with profile.
• Audio 2: Audio 2 transcoded by this block (A/B/C/D) will be
associated with profile
• All in Channel: Audio 1 and generated by this block
(A/B/C/D) will be associated with profile
• All in GOP Group: All audio transcoded by GOP aligned
blocks will be associated with profile.
Scene Change
Detection
Specify any of the below options:
• P-Frames
• Disabled.
CABAC
Enable or disable CABAC entropy coding.
Reference B
Enable or disable hierarchical B frames.
All non-transcoded audio and other components are passed through and associated
with all profiles.
Reference B Frames and CABAC parameters are available for each screen by expanding the
settings view through clicking on the icon in the left most column.
The question mark icon opens up a detailed explanation of the various modes configurable
through the Use Case setting. Each path consists of a finite amount of video processing power.
Fundamentally the encoding complexity of a HD profile is much higher than the complexity of a
low resolution profile. Therefore the Universal Transcoder- Multiscreen can encode more low
resolution profiles than high resolution profiles.
The resource can be configured in 16 different Use Cases or modes. The various modes give
the possibility of partitioning the processing power to match the multiscreen profile requirements
of any device. The Use Cases available are:
